SP-3U/6U Series
Wide-range High-power Programmable DC Power Supply
Product Features
Large color touch screen with intuitive interface provides an excellent intuition operational experience
3-phase input voltage meets worldwide power distribution regulation, AC mains 187~305Vac/340~480Vac for optional
Constant voltage (CV), constant current (CC) and constant power (CP) operation mode, CC or CV working priority setting
Adjustable voltage/current slew rate
DDS arbitrary function generator*
Solar panel I-V curve simulation function*
Smart 3-stage charging algorithm simulation*
Battery simulator function*
List/ Step mode programming
TTL/Analog control and monitoring
Built-in standard automotive power network voltage curves*
Full protection: OVP, OCP, OPP and OTP protection
Supports master-slave mode, paralleling up to 16 units
Supports SCPI commands, provides web GUI function
* Only professional version units support these functions
Function & Advantage
The large color touch screen provides simple and fast operation for customers, real-time update of display output data and power status.The actual values are displayed with bigger char acters, so they can be read from a large distance.
3-phase input voltage range 187~480Vac meets worldwide power distribution regulation. 36kW/6U high density, higher efficiency, lower ripple and fast response make it ideal for test requirements in different periods of different applications. This series power supply can have from one to three internal 6kW power blocks, each of which is connected across a separate phase of the 3-phase AC mains. The following figures illustrate how to install three 6kW units or three 12kW units to obtain a balanced current draw on the 3-phase AC mains.
This series power supply provides CC/CV priority function allows the user to select suitable mode correspond to test requirement, let the output be voltage high speed or current no overshoot mode. Below shows an application of CC priority to avoid current overshoot during LED test.
This series power supply provides adjustable rise and fall time setting for voltage and current. Adjustable time range 1ms~24h.
This series power supply provides List/Program/Step modes for output waveform programming. Users can edit the voltage/current value & the time of each step in advance and provide the power supply with a trigger signal. Then the preset sequences / waveform will be executed automatically according to the defined files. Sequence mode supports link between multiple files, the user can set the repeat times of each file and the total repeat times of the complete sequence file.
< Professional Version Power Supply Function >
This series power supply includes a true function generator which can generate typical functions as displayed below, convenient for editing or directly recall. Additional to the standard functions, this arbitrary generator is accessible for the creation and execution of complex sets of functions, which is can be used for testing purposes in development and production.
This series power supply has built-in German DIN40839 standard voltage curve for the automotive power network and the international standard ISO-16750-2 pulse waveform. The fast rise/fall response time together with arbitrary function generate ability make it can truly simulate the influence on the performance of automotive electronic equipment under different test conditions, is the preferred power testing instrument in the automotive electronics industry.
The power supply provides an unique feature to simulate the output characteristics of a solar array includes Curve Mode, User-defined Mode and SAS Mode. With Curve mode, only need to set four parameters to simulate the solar array I-V curve. With User-defined mode, user can shape an I-V curve by entering up to 4096 points to simulate dynamic cloud cover effect which is useful for MPPT performance evaluation on PV inverter device. With built-in SAS mode, user can set the parameters to simulate I-V curve characteristic output and generate reports.
This series power supply adopts 3-stage charging algorithm, built-in charging curves which is suitable for the commonly known types of batteries on the market. Users can directly recall the default curves or change the switching conditions at different charging stage according to the test requirement. Through the internal design, it improved and optimized hardware improvements, the current passing from the battery to power supply will be less than 10mA at any battery voltage when turn off the power supply. Thus avoid battery capacity loss, even when there is no anti reverse irrigation equipment.
This series power supply built-in typical battery internal resistance curves and discharging curves can easily simulate battery behavior in real-case.
Options & Accessories
-
Handles (standard)
-
Input protective cover (standard)Standard for 3U models
-
Input protective cover (standard)Standard for 6U models
-
Setup package (standard)
-
RS-232 communication cable (standard)For RS-232 communication
-
USB communication cable (optional)For USB communication
-
Parallel cable (optional)Connect for master-slave communication
-
Power cable (optional)4M or 10M
-
GPIB & LAN card & communication cable (optional)for communication between GPIB and LAN
-
CAN card (optional)For CAN communication
-
Remote I/O control and monitor card (optional)For external analog control and monitoring
-
Professional version upgrade software (optional)Upgrade version from advanced to professional
Model Search
| Model | Voltage | Current | Power | Voltage Ripple | Current Ripple | Response（Voltage Increase） | Response（Voltage Drop） | Size | |
| SP80VDC6000W | 80V | 200A | 6000W | <180mVpp, <15mVrms | <100mArms | <15ms (No load), <30ms (Full load) | <850ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP80VDC12000W | 80V | 400A | 12000W | <288mVpp, <23mVrms | <200mArms | <15ms (No load), <30ms (Full load) | <850ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP80VDC18000W | 80V | 600A | 18000W | <320mVpp, <25mVrms | <300mArms | <15ms (No load), <30ms (Full load) | <850ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP80VDC24000W | 80V | 800A | 24000W | <320mVpp, <25mVrms | <360mArms | <15ms (No load), <30ms (Full load) | <850ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP80VDC30000W | 80V | 1000A | 30000W | <320mVpp, <25mVrms | <450mArms | <15ms (No load), <30ms (Full load) | <850ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP80VDC36000W | 80V | 1200A | 36000W | <320mVpp, <25mVrms | <540mArms | <15ms (No load), <30ms (Full load) | <850ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP165VDC12000W | 165V | 180A | 12000W | <540mVpp, <50mVrms | <100mArms | <15ms (No load), <30ms (Full load) | <900ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP165VDC24000W | 165V | 360A | 24000W | <540mVpp, <50mVrms | <200mArms | <15ms (No load), <30ms (Full load) | <900ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP165VDC36000W | 165V | 540A | 36000W | <540mVpp, <50mVrms | <300mArms | <15ms (No load), <30ms (Full load) | <900ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP250VDC18000W | 250V | 180A | 18000W | <550mVpp, <50mVrms | <100mArms | <15ms (No load), <30ms (Full load) | <950ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP360VDC6000W | 360V | 42.5A | 6000W | <320mVpp, <55mVrms | <21mArms | <15ms (No load), <115ms (Full load) | <650ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP360VDC12000W | 360V | 85A | 12000W | <320mVpp, <55mVrms | <43mArms | <15ms (No load), <115ms (Full load) | <650ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP360VDC18000W | 360V | 127.5A | 18000W | <320mVpp, <55mVrms | <64mArms | <15ms (No load), <115ms (Full load) | <650ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP360VDC24000W | 360V | 170A | 24000W | <350mVpp, <60mVrms | <85mArms | <15ms (No load), <115ms (Full load) | <650ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP360VDC30000W | 360V | 212.5A | 30000W | <350mVpp, <60mVrms | <106mArms | <15ms (No load), <115ms (Full load) | <650ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP360VDC36000W | 360V | 255A | 36000W | <350mVpp, <60mVrms | <128mArms | <15ms (No load), <115ms (Full load) | <650ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP500VDC6000W | 500V | 32A | 6000W | <600mVpp, <150mVrms | <16mArms | <15ms (No load), <80ms (Full load) | <1500ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP500VDC12000W | 500V | 64A | 12000W | <650mVpp, <160mVrms | <32mArms | <15ms (No load), <80ms (Full load) | <1500ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP500VDC18000W | 500V | 96A | 18000W | <650mVpp, <160mVrms | <48mArms | <15ms (No load), <80ms (Full load) | <1500ms (No load),<15ms (Full load) | 3U | Inquiry |
| SP500VDC24000W | 500V | 128A | 24000W | <650mVpp, <160mVrms | <64mArms | <15ms (No load), <80ms (Full load) | <1500ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP500VDC30000W | 500V | 160A | 30000W | <650mVpp, <160mVrms | <80mArms | <15ms (No load), <80ms (Full load) | <1500ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP500VDC36000W | 500V | 192A | 36000W | <650mVpp, <160mVrms | <96mArms | <15ms (No load), <80ms (Full load) | <1500ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP750VDC6000W | 750V | 21A | 6000W | <900mVpp, <225mVrms | <11mArms | <15ms (No load), <80ms (Full load) | <600ms (No load), <20ms (Full load) | 3U | Inquiry |
| SP750VDC12000W | 750V | 42A | 12000W | <1000mVpp, <250mVrms | <22mArms | <15ms (No load), <80ms (Full load) | <600ms (No load), <20ms (Full load) | 3U | Inquiry |
| SP750VDC18000W | 750V | 63A | 18000W | <1000mVpp, <250mVrms | <33mArms | <15ms (No load), <80ms (Full load) | <600ms (No load), <20ms (Full load) | 3U | Inquiry |
| SP750VDC24000W | 750V | 84A | 24000W | <1000mVpp, <250mVrms | <44mArms | <15ms (No load), <80ms (Full load) | <600ms (No load), <20ms (Full load) | 6U | Inquiry |
| SP750VDC30000W | 750V | 105A | 30000W | <1000mVpp, <250mVrms | <55mArms | <15ms (No load), <80ms (Full load) | <600ms (No load), <20ms (Full load) | 6U | Inquiry |
| SP750VDC36000W | 750V | 126A | 36000W | <1000mVpp, <250mVrms | <66mArms | <15ms (No load), <80ms (Full load) | <600ms (No load), <20ms (Full load) | 6U | Inquiry |
| SP1000VDC12000W | 1000V | 32A | 12000W | <1500mVpp, <320mVrms | <22mArms | <15ms (No load), <85ms (Full load) | <1700ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP1000VDC18000W | 1000V | 42.5A | 18000W | <1000mVpp, <150mVrms | <25mArms | <15ms (No load), <120ms (Full load) | <650ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP1000VDC24000W | 1000V | 64A | 24000W | <1500mVpp, <320mVrms | <26mArms | <15ms (No load), <85ms (Full load) | <1700ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP1000VDC36000W | 1000V | 96A | 36000W | <1500mVpp, <320mVrms | <48mArms | <15ms (No load), <80ms (Full load) | <1700ms (No load), <15ms (Full load) | 6U | Inquiry |
| SP1500VDC12000W | 1500V | 21A | 12000W | <2500mVpp, <600mVrms | <11mArms | <15ms (No load), <80ms (Full load) | <700ms (No load), <20ms (Full load) | 3U | Inquiry |
| SP1500VDC18000W | 1500V | 32A | 18000W | <1950mVpp, <650mVrms | <22mArms | <15ms (No load), <90ms (Full load) | <1800ms (No load), <15ms (Full load) | 3U | Inquiry |
| SP1500VDC24000W | 1500V | 42A | 24000W | <2500mVpp, <600mVrms | <22mArms | <15ms (No load), <80ms (Full load) | <700ms (No load), <20ms (Full load) | 6U | Inquiry |
| SP1500VDC36000W | 1500V | 63A | 36000W | <2500mVpp, <600mVrms | <33mArms | <15ms (No load), <80ms (Full load) | <700ms (No load), <20ms (Full load) | 6U | Inquiry |
| SP2250VDC18000W | 2250V | 21A | 18000W | <3200mVpp, <750mVrms | <11mArms | <15ms (No load), <85ms (Full load) | <800ms (No load), <20ms (Full load) | 3U | Inquiry |
